Wago, 734-104, 734 Series, Light Grey, 1.5mm², 1-conductor 4-Pole Female Connector, Push-in CAGE CLAMP®, Pin Spacing 3.5mm, 160V, 10 Amps,

The female connector/socket (item number 734-104) enables smooth electrical installation. Rely on tried-and-tested safety when designing your device: PCB connectors offer a wide range of application possibilities. This female connector/socket requires stripped insulation with lengths between 6 and 7mm for the conductor connection. This product uses CAGE CLAMP® technology. The reliable and maintenance-free CAGE CLAMP® universal connection offers the option of connecting all types of conductors with a cage clamp without the need for pre-treatment of the conductors. This eliminates the need to crimp on wire end ferrules. The dimensions are width x height x depth (16.2 x 13.4 x 18.6mm). Depending on the conductor type, the female connector/socket is suitable for conductor cross-sections from 0.08mm² to 1.5mm². Tin was used for the contact surface. This female connector/socket is operated using an operating tool. WAGO's MCS – "Multi Connection System" comprises a total of seven families with pitches from 2.5mm to 10.16mm and offers a wide range of application possibilities with a conductor cross-section range from 0.08 to 25mm².
